4.2.3 EtherCAT product codes
The product codes serve to assign device descriptions to the corresponding devices. Device
descriptions can be installed via the device repository.
Importing missing field devices
( 59)
 The product codes are part of the device ID.
 Structure of the device ID: _
If, for instance, a device available at the fieldbus witout an installed device description is
detected during a Fieldbus scan with the »EtherCAT Configurator«
( 47)
, a message with
the device ID as hexidecimal value is displayed.
In the example, the device description for a Lenze Servo Drive 9400 HighLine, actuator –
speed, is not installed (0x38079CD9
hex
= 940023001
dec
).
Product codes for Servo Drives 9400
Identification Meaning
Manufacturer ID Clear identification for the manufacturer, for Lenze devices: 0x3B
hex
(59
dec
)
Product code Product code of the product range/the device
Revision number Revision number, consists of Major Revision (CANopen behaviour) and
Minor Revision (device version)
Product code [dec] Meaning
9 4 0 0 2 1 x x x Servo Drive 9400 in general
9 4 0 0 2 2 x x x Servo Drive 9400 StateLine
9 4 0 0 2 3 x x x Servo Drive 9400 HighLine
9 4 0 0 2 4 x x x Servo Drive 9400 TopLine
9 4 0 0 2 5 x x x Servo Drive 9400 PLC
9 4 0 0 2 6 x x x Servo Drive 9400 V/R (regenerative power supply module)
Applications:
0 0 0 Empty application
0 0 1 Actuating drive speed
0 0 2 Actuating drive torque
0 0 3 Electronic gearbox
0 0 4 Synchronism with mark synchronisation
0 0 5 Table positioning
0 0 6 Positioning sequence control
0 0 7 PLC application
0
0
0
...
9
8
9
Reserved
...
Reserved
1 x x Reserved for device profiles
1 0 1 CiA402
2 x x Reserved for Lenze applications
2 0 1 Regenerative power supply module application
