Control technology | EtherCAT communication manual
Parameter reference
Interface parameters of the MC-ETC communication card in slot 2
C1596/32
C1596/33
C1596/35
C1596/36
C1596/37
C1596/38
Parameter | Name:
C1596/32 | ECAT Processing Unit Error Counter
Data type: UNSIGNED_8
Index: 22979.32
d
=
0x59C3.0x20
h
Number of errors which have occurred in the processing unit.
EtherCAT slave controller error counter register "0x030C": Internal slave error
Display range
(min. value | unit | max. value)
0 255
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1596/33 | ECAT PDI Error Counter
Data type: UNSIGNED_8
Index: 22979.33
d
=
0x59C3.0x21
h
Number of internal errors of the slave indicated by the process data interface.
Display range
(min. value | unit | max. value)
0 255
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1596/35 | ECAT Lost Link Counter Port 0
Data type: UNSIGNED_8
Index: 22979.35
d
=
0x59C3.0x23
h
Number of connection interruptions on port 0
Display range
(min. value | unit | max. value)
0 255
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1596/36 | ECAT Lost Link Counter Port 1
Data type: UNSIGNED_8
Index: 22979.36
d
=
0x59C3.0x24
h
Number of connection interruptions on port 1
Display range
(min. value | unit | max. value)
0 255
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1596/37 | ECAT Lost Link Counter Port 2
Data type: UNSIGNED_8
Index: 22979.37
d
=
0x59C3.0x25
h
Number of connection interruptions on port 2
Display range
(min. value | unit | max. value)
0 255
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1596/38 | ECAT Lost Link Counter Port 3
Data type: UNSIGNED_8
Index: 22979.38
d
=
0x59C3.0x26
h
Number of connection interruptions on port 3
Display range
(min. value | unit | max. value)
0 255
; Read access Write access CINH PLC STOP No transfer
