Control technology | EtherCAT communication manual
Parameter reference
Interface parameters of the MC-ETC communication card in slot 1
12.2
Interface parameters of the MC-ETC communication card in slot 1
The parameters are listed in numerically ascending order.
C1074
C1080/1
C1080/2
C1080/3
C1080/4
Parameter | Name:
C1074 | ECAT MAC address
Data type: VISIBLE_STRING
Index: 23501
d
= 5BCD
h
MAC address of the interface
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/1 | ECAT Master Configuration Date
Data type: DATE
Index: 23495.1
d
=
0x5BC7.0x01
h
Date of the master configuration file in the file system of the IPC
The file manager determines the date of the master configuration file in the index ...\storage\IPC\PLC. If this file
does not exist, the date "01/01/1980 00:00:00" is displayed.
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/2 | ECAT Master Config Checksum
Data type: UNSIGNED_32
Index: 23495.2
d
=
0x5BC7.0x02
h
Checksum of the master configuration file in the file system of the IPC
The data manager determines the checksum of the master configuration file in the ...\storage\IPC\PLC directory. If
this file does not exist, the value "0x00000000" is displayed.
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/3 | ECAT Stack Master Checksum
Data type: UNSIGNED_32
Index: 23495.3
d
=
0x5BC7.0x03
h
The stack determines the checksum of the loaded/active master configuration file. If there is no loaded/active
master configuration file, the value "0x00000000" is displayed.
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/4 | ECAT Bus Scan Match
Data type: UNSIGNED_8
Index: 23495.4
d
=
0x5BC7.0x04
h
Brief information whether the master configuration corresponds to the physical bus structure. The master
configuration of the stack is compared with the actual bus structure.
Selection list
(Lenze setting printed in bold)
Information
0 No match
The master configuration does not correspond to the bus
structure.
1 OK
The master configuration corresponds to the bus
structure.
;
Read access Write access CINH PLC STOP No transfer
