Diagnostics
System error messages
160
L
DMS 3.1 EN 01/2011 TD17
0x9811000B
EC_E_INVALIDPARM
CTRL An API function has been called with incorrect parameters.
0x9811000C
EC_E_NOTFOUND
CTRL An API function has been called with an invalid slave ID.
0x9811000E
EC_E_INVALIDSTATE
ISW Invalid state
0x9811000F
EC_E_TIMER_LIST_FULL
ISW Not enough application memory available.
0x98110010
EC_E_TIMEOUT
All A time-out is active.
0x98110011
EC_E_OPENFAILED
ISW Internal software error (numerous possible causes)
0x98110012
EC_E_SENDFAILED
LLA The transmission of the frame has failed.
0x98110013
EC_E_INSERTMAILBOX
CFG The mailbox command cannot be enqueued on the internal queue.
0x98110014
EC_E_INVALIDCMD
ISW Unknown mailbox command code
0x98110015
EC_E_UNKNOWN_MBX_
PROTOCOL
ISW Unknown mailbox protocol
Mailbox command ID with unknown protocol assignment
0x98110016
EC_E_ACCESSDENIED
ISW Access denied (internal software error on the master)
0x9811001A
EC_E_PRODKEY_INVALID
CFG The evaluation version of the master is used. The master enters the "Stop" mode after 30 minutes.
0x9811001B
EC_E_WRONG_FORMAT
PRJ The XML file contains no or faulty content.
0x9811001C
EC_E_FEATURE_DISABLED
CTRL Attempt to execute a non-existing or deactivated function.
0x9811001E
EC_E_BUSCONFIG_
MISMATCH
PRJ The bus configuration of the master and the connected slaves in the XML file does not comply with the
physical bus structure.
0x9811001F
EC_E_CONFIGDATAREAD
PRJ The XML file cannot be read.
0x98110021
EC_E_XML_CYCCMDS_
MISSING
PRJ The XML file of the master does not contain any cyclic commands.
0x98110022
EC_E_XML_ALSTATUS_
READ_MISSING
PRJ The XML file of the master does not contain the command for reading the AL Status Register.
0x98110023
EC_E_MCSM_FATAL_ERROR
ISW The master state machine is in an invalid state.
0x98110024
EC_E_SLAVE_ERROR
SLV The slave cannot be addressed.
0x98110025
EC_E_FRAME_LOST
SLV An EtherCAT frame was lost on the bus, i.e. it has not been received. If this error occurred frequently, this
indicates the wiring may be faulty.
0x98110026
EC_E_CMD_MISSING
SLV The received EtherCAT frame is not complete.
0x98110028
EC_E_INVALID_DCL_MODE
CTRL This function cannot be used when DC latching is in the "Auto Read" operating mode.
0x98110029
EC_E_AI_ADDRESS
SLV The bus configuration (XML file of the master) does not correspond with the connected slaves. This error
only occurs if a previously existing slave disappears.
0x9811002A
EC_E_INVALID_SLAVE_
STATE
CTRL The mailbox commands are not permissible in the current slave state.
0x9811002B
EC_E_SLAVE_NOT_
ADDRESSABLE
SLV The slave has been switched on/off.
0x9811002C
EC_E_CYC_CMDS_
OVERFLOW
PRJ Error during XML file creation by the configurator
0x9811002D
EC_E_LINK_DISCONNECTED
SLV The EtherCAT cable is not connected to the control unit/is not plugged in.
0x9811002E
EC_E_MASTERCORE_
INACCESSIBLE
RAP The connection to the master (server) is interrupted or the master has been stopped.
Error number [hex]
Designation
Error type Description
