1.2 Conventions used
This documentation uses the following conventions to distinguish between different types
of information:
Type of information Writing Examples/notes
Spelling of numbers
Decimal separator Point The decimal point is always used.
For example: 1234.56
Text
Version information Blue text colour All information valid for or from a certain software
version, is indicated accordingly in this
documentation.
Example: This function extension is available from
software version V3.0!
Program name » « The Lenze PC software »Engineer«...
Window Italics The Message window... / The Options dialog box...
Variable identifier By setting bEnable to TRUE...
Control element Bold The OK button... / the Copy command... / the
Characteristics tab... / the Name input field...
Sequence of menu
commands
If the execution of a function requires several
commands in a row, the individual commands are
separated by an arrow: Select File  Open to ...
Shortcut Use to open the online help.
If a key combination is required for a command, a "+"
is placed between the key identifiers: With
+...
Program code Courier
IF var1 < var2 THEN
a = a + 1
END IF
Keyword Courier bold
Hyperlink Underlined Optically highlighted reference to another topic. It is
activated with a mouse-click in this documentation.
Symbols
Page reference ( 10) Optically highlighted reference to another page. It is
activated with a mouse-click in this documentation.
Step-by-step instructions  Step-by-step instructions are indicated by a
pictograph.
