9 Consumables
- When inserting the chart cassette, take care that it is
centered on the tear-off edge and – guiding it with the
thumb and index finger – insert it into the cassette slot and
push it up gently, until the holding/ejector catch snaps into
position.
- When the cassette has been inserted, the paper feed
should immediately take up the slack in the paper (about
10mm feed).
- If the paper feed does not start up, then the cassette will
have to be removed and replaced in the correct position.
- Check that the holding catch is in the final (latched)
position.
