61
4 Configuration table
Limit comparator Configuration level 1
➔ Limit comparator
X Limit comparator 1 — 8 Select limit comparator
Limit value: -9999 to +9999 Enter value for limit
Lower differential: 0 — 9999 Enter the hysteresis below
the limit value
Upper differential: 0 — 9999 Enter the hysteresis above
the limit value
LK-function:
(LK=limit comparator) lk7, lk8 Select limit comparator
function
Probe break: OFF = 0, ON = 1,
CONST. Determine relay state for a
probe break
(CONST. = constant: limit
state will be held)
Limit-text status: OFF, ON Enter status for the print-
out of out-of-limit signals
(for OFF, text entries are
not required)
TXT L:
(L = lower) 16 characters Text for going below the
limit value
TXT H:
(H = higher) 16 characters Text for exceeding the limit
value
Channel: 1 — 3 or 1 — 6 Select reference channel
for the limit comparator
Limit operation
(limit feed) Configuration level 1
➔ Limit feed
X Limit feed 1 — 3 or 1 — 6 Select reference channel
Status: ON, OFF Select status for limits
Low: -9999 to +9999 Enter lower limit, if status
is ON
High: -9999 to +9999 Enter upper limit, if status
is ON
Parameter Value/selection Description
