57
4 Configuration table
4.2.3 Configuration level 1 (C1-level)
Parameter Value/selection Description
Plot status Configuration level 1
➔ Plot status
X Plot status 1 — 3 or 1 — 6
Setting for each writing
channel: should the signal
trace be printed on the
chart and appear in the
statistical report or not.
Status: ON, OFF
Measurement input Configuration level 1
➔ Measurement input
X Measurement input
Type:
1 — 3 or 1 — 6
RES.THERMOMETER
THERMOCOUPLE
POTENTIOMETER
RES. TRANSMITTER
VOLTAGE
CURRENT
SHUNT
Select the type of probe/
sensor and input signal,
determine the measure-
ment range + filter time
constant for each input
channel.
Configuration level 1
➔ Measurement input
Type: Resistance
thermometer
Characteristic: Pt100, Pt100 JIS, Pt500,
Pt1000, Ni100, X1, X2,
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter.
Connection: 2/3-wire
4-wire Determine the type of
connection for the
resistance thermometer.
Unit:
(dimension) °C, °F
Range start: -9999 to +9999 Enter start of
measurement range
1
Range end: -9999 to +9999
Measurement span
≥
15°C
Enter end of
measurement range
1
Filter: 0.0 — 50.0sec Enter filter constant
Configuration level 1
➔ Measurement input
Type: thermocouple
Characteristic: L, J, U, T, K, E, N, S, R, B,
X1, X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Unit:
(dimension) °C, °F
1. The limits for range start and range end differ according to the characteristic
