4 Configuration table
68
External report Configuration level 3
➔ External report
X External report
Contact:
1 - 2
OFF, Log. input 1,
Log. input 2, Log. input 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8
Select report/instance
number
Select logic input
Key inhibit Configuration level 3
➔ Key inhibit
Contact: OFF, Log. input 1,
Log. input 2, Log. input 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8 Select logic input
Event traces Configuration level 3
➔ Event traces
X Event trace 1 — 8 Select event trace
Trace status: OFF, ON Enter status for the print-
out of the event trace
Source: LOG.INPUT
LIMITCOMP. Select source for event
trace, if status is ON
Parameter Value/selection Description
