63
4 Configuration table
4.2.4 Configuration level 2 (C2-level)
Parameter Value/selection Description
Unit name Configuration level 2
➔ Unit name
Text: 16 characters Enter instrument
designation
Open-collector
output Configuration level 2
➔ Open-collector output
X Output 1 — 4 Select open-collector
output
Status: OFF, ON Enter status
Speed in limit
operation
(feed limit) Configuration level 2
➔ Feed limit
Feed limit: 0, 5, 10, 20, 60, 120, 240,
300, 360, 600, 720mm/h
Select speed
The recorder switches to
this chart speed, if the
limits configured in the
parameter Configuration
level 1
Î Limit feed are
infringed
Timed operation
(feed time) Configuration level 2
➔ Feed time
Feed time: 0, 5, 10, 20, 60, 120, 240,
300, 360, 600, 720mm/h
Select speed
This chart speed only
applies during the defined
period of time
from - to: Enter any time for “from” Enter start time
from - to: Enter any time for “to” Enter end time
Print speed change Configuration level 2
➔ Print speed change
Status: OFF, ON
Select the status for print-
out of an alteration or
change-over of the chart
speed
Print the
“Power on” text Configuration level 2
➔ Print the "power on" text
Status: OFF, ON Status for print-out of the
“power on” text (if OFF:
text entry not required)
Text: 16 characters Enter ”power on” text
Print the
“Power off” text Configuration level 2
➔ Print the “power off” text
Status: OFF, ON Status for the print-out of
the “power off” text (if OFF:
text entry is not required)
Text: 16 characters Enter “power off” text
Print the
scaling Configuration level 2
➔ Print scale
Spacing: OFF, 30, 60, 90cm
Determine the regular in-
terval at which the scaling
should be printed in the
chart
