3 Operation and visualisation
48
3.5.12 Incrementing the two event counters
The event counter is assigned to a freely selected logic input. Every time the
corresponding logic input is closed, the event counter is incremented. It can
be pre-loaded with a value through the setup program and the keys on the re-
corder (Configuration level 3
Î Event counter).
Every time it is incremented, the event is registered by printing the time and
the programmed text, followed by the current state of the counter.
H
The time reference mark “_” will not be printed, since the print-out
may appear after being delayed in the print queue.
v Section 3.5.4 “Limit comparator texts, external text, binary-
linked external text”
H
If the counter state is larger than 99999, then the number can no
longer be displayed. The print-out will be “ ***** “ for the counter
state.
13:22 Charge no. 23
