2 Instrument description

Example of the basic status for a 6-channel recorder

Operating level
(S-level)

The operating level can be accessed from the basic status with the aid of the
h + R keys, from the parameter level by using e.

Signal acquisition and processing remain active in this level.

The following parameters can be altered:

- chart speed

- print test

- service print

- version number (display only)

BUILDING28 03.11.98 08 : 54

Display instrument name, date and time

h R

1 -5.321m/h

2 +34.67°C

Display the first 2 channels in one frame

h R

3 +76.20°C

4 +20.35bar

Display the next two channels in one frame

h R

5 +35.08°C

6 +007.4U/m

Display the next two channels in one frame

h R

1 CONVEYOR -5.321m/h

Display the 6 channels, each in a separate frame

h R

2 MIXER +34.67°C

h R

3 MOT7. BEARING +76.20°C

h R

4 PRESSURE

+20.35 bar

h R

5 VENT.TEMP. +35.08°C

h R

6 SHAFT

+007.4U/m

It the operating level is active, then signal acquisition, processing
and recording, as well as limit monitoring, will all continue to be
performed.
