4 Configuration table
58
Range start:
-9999 to +9999
Enter start of
measurement range
1
Range end:
-9999 to +9999
Meas. span
≥
100°C
for Type S, R, B
≥
500°C
Enter end of
measurement range
1
Cold junction:
(temp. comp.)
INTERN Pt 100
EXT. CONST.
Select cold junction
Cold junct. temp.:
(comp. temp.)
Value range:
-50 to +100°C
Enter cold junction temp.,
if cold junction = EXT.
CONST.
Filter:
0.0 — 50.0sec
Enter filter constant
Configuration level 1
➔ Measurement input
Type: Potentiometer
Characteristic:
linear, X1, X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Connection:
2/3-wire
4-wire
Determine type of connec-
tion for the potentiometer
Start res. Ro:
0
≤
Ro
≤
4000
Ω
Enter start resistance
Res. range Rp:
6
≤
Rp
≤
4000
Ω
Ro + Rp
≤
4000
Ω
Meas. span
≥
6
Ω
Enter measurement range
(resistance Rp)
Filter:
0.0 — 50.0sec
Enter filter constant
Configuration level 1
➔ Measurement input
Type: res. transmitter
Characteristic:
linear, X1, X2
X1 = customer-specific
linearisation 1
X2 = customer-specific
linearisation 2
(with X1 or X2 : followed
immediately by the entry
for the filter parameter)
Start res. Ra:
0
≤
Ra
≤
4000
Ω
Enter start resistance
Res. range Rs:
6
≤
Rs
≤
4000
Ω
Enter measurement range
1. The limits for range start and range end differ according to the characteristic
Parameter
Value/selection
Description
