7 Electrical connection
74
7.2 Technical data
Thermocouple
input
Resistance
thermometer
input
Measurement range
Linearisation accuracy
1
Fe-Con L
Fe-Con J EN 60584
Cu-Con U
Cu-Con T EN 60584
NiCr-Ni K EN 60584
NiCr-CuNi E EN 60584
NiCrSi-NiSi N E 60584
Pt10Rh-Pt S EN 60584
Pt13Rh-Pt R EN 60584
Pt30Rh-Pt6Rh B
EN 60584
-200 to
+900°C
-210 to +1200°C
-200 to
+600°C
-270 to
+400°C
-270 to +1372°C
-270 to +1000°C
-270 to +1300°C
-50 to +1768°C
-50 to +1768°C
0 to
1820°C
±0.2%
±0.2% above -200°C
±0.3%
±0.5% above -200°C
±0.2% above -150°C
±0.2% above -200°C
±0.2% above -150°C
±0.5% above 0°C
±0.5% above 0°C
±0.5% above 500°C
Shortest measurement span
Types L, J, U, T, K, E, N:
Types S, R, B:
100°C
500°C
Range start/end
freely programmable within the limits, in 0.1°C steps
Cold junction
Pt100 internal or thermostat as external constant
Cold junction accuracy
(internal)
± 1°C
Cold junction temperature
(external)
-50 to +100°C, adjustable through setup software
Measurement time
for 3 channels < 2sec; for 6 channels < 4sec
Input filter
2nd. order digital filter; filter constant adjustable from 0 to 50.0sec
Features
also programmable in °F; customer-specific linearisation
1. The linearisation accuracy refers to the maximum measurement span.
The linearisation accuracy is reduced for shorter spans.
Connection
Range
Linearisation
accuracy
Meas.
current
Pt 100 EN 60751
2/3-wire
2/3-wire
4-wire
4-wire
-200 to +250°C
-200 to +850°C
-200 to +250°C
-200 to +850°C
±0.6°C
±1.0°C
±0.5°C
±0.8°C
500
μ
A
250
μ
A
500
μ
A
250
μ
A
Pt 100 JIS
2/3-wire
2/3-wire
4-wire
4-wire
-200 to +260°C
-200 to +649°C
-200 to +260°C
-200 to +649°C
±0.6°C
±1.0°C
±0.5°C
±0.8°C
500
μ
A
250
μ
A
500
μ
A
250
μ
A
Pt 500 DIN
2/3-wire
2/3-wire
4-wire
4-wire
-200 to +150°C
-200 to +850°C
-200 to +150°C
-200 to +850°C
±0.6°C
±1.0°C
±0.5°C
±0.8°C
250
μ
A
250
μ
A
250
μ
A
250
μ
A
Pt 1000 DIN
2/3-wire
2/3-wire
4-wire
4-wire
-200 to +250°C
-200 to +850°C
-200 to +250°C
-200 to +850°C
±0.6°C
±1.0°C
±0.5°C
±0.8°C
500
μ
A
250
μ
A
500
μ
A
250
μ
A
Ni 100
2/3-wire
2/3-wire
4-wire
4-wire
-60 to +125°C
-60 to +180°C
-60 to +125°C
-60 to +180°C
±0.6°C
±1.0°C
±0.5°C
±0.8°C
500
μ
A
250
μ
A
500
μ
A
250
μ
A
Connection type
2-, 3- or 4-wire circuit
Shortest measurement span
15°C
Probe lead resistance
max. 30
Ω
per core for 4-wire circuit
max. 20
Ω
per core for 2- and 3-wire circuit
for Pt100 up to 260°C max. 10
Ω
per core in
2- and 3-wire circuit
