3 Electrical connection

30

2012-12-01/00561071 [SCR Power Controller TYA201]

3.2.5 Type 709061/X-0X-250-XXX-XXX-XX-25X

Devices with a load current of 200 to 250 A are equipped with plug-in screw
terminals in the control section and cable lugs in the power section.

Voltage supply
for
fan

Terminal

Version

Conductor cross-section

Maximum
tightening
torque

X2_1 and X2_2

Slotted screws, blade width 2 mm

0.2 to 1.5 mm

2

0.25 Nm

X3

Slotted screws, blade width 3 mm

0.5 to 2.5 mm

2

0.5 Nm

U2, U1

M8 hexagon screws, width across
flats 13 mm

95 to 150 mm

2

12 Nm

For applications according to UL, only 75 °C copper conductors may be used!

N/L2, V, L1

Slotted screws,
blade width 3 mm

0.5 to 4 mm

2

or

(0.5 to 2.5 mm

2

with ferrule)

(for UL application AWG 20-
12)

0.5 Nm

Ground terminal
PE

M8 setscrew with hexagon
nut, width across flats 13 mm

Cable lug
hole: 8 mm

12 Nm

Fan X14

Slotted screws, blade width 3 mm

0.5 to 2.5 mm

2

0.5 Nm

A

Depending on the load voltage, the fan terminal X14 must be supplied with the
voltage specified below.
The lead protection must be between 2 A and a maximum of 5 A.
The fan is temperature-controlled, switches on automatically when the device
temperature reaches 85 °C, and remains in operation until the device tempera-
ture falls below 70 °C.

Load voltage on the pow-
er controller

Tolerances

Fan specifica-
tions

Load voltage AC 24 V

-20 to +15 %, 45 to 63 Hz

AC 24 V / 30 VA

Load voltage AC 42 V

-20 to +15 %, 45 to 63 Hz

Load voltage AC 115 V

-15 to +6 %, 45 to 63 Hz

AC 115 V / 30 VA

Load voltage AC 230 V

-15 to +6 %, 45 to 63 Hz

AC 230 V / 30 VA

Load voltage AC 265 V

Load voltage AC 400 V

Load voltage AC 460 V

Load voltage AC 500 V
