Heidolph LABOROTA 4000 up to 4003 User Manual
Page 78

About this document
76
Laborota 4000/4001 efficient, 4010/4011 digital, 4002/4003 control
1.02
Warnings have the following structure (here an example of the DANGER
level):
The type and source of the danger can be found here.
The possible consequences of not taking action to avoid the danger can be
found here.
The measure to avoid the danger can be found here.
Symbols and highlighting
Symbol
Use
Explanation
Precondition
This must be fulfilled before you follow an instruction.
Instruction
Description of required action
1.
2.
Instruction, multiple
steps
Actions must be performed in the stated order. Deviating
from the order can result in damage to the instrument or
accidents.
Outcome
Result
The result of the previous action is shown indented.
-
Bullet points,
two levels
Lists
(see chapter
Cross reference
References to images, tables, other chapters or other
manuals
Example
Switch designation
Highlighting of designations of switches or buttons
Note
Important information for understanding the instrument or
optimising operation
Table 1-2: Symbols and highlighting
Position numbers in images are shown in parentheses in the text. If an image
number is not stated, the position number refers to the image or chart directly
above the text. When referring to a different image or chart, the image number
will be specified, e.g. (Fig. 4-1 (11)).
DANGER
Images
