ETC Unison DRd Dimming Rack Enclosure User Manual
Page 52

48
DRd Enclosure Installation Manual
a: Insert the connector end through the opening in the bottom of the enclosure.
The connector is designed to snap into place without additional hardware,
therefore slight force may be required to ensure the connector installs
properly.
Step 2:
Connect the two pin receptacle labeled “RideThru/Batt” on the DRd right I/O
board.
See “DRd Right I/O Data Terminations” on page 34.
Step 3:
Secure the wiring harness to the enclosure using the cable tie and cable tie
mount supplied with the BatteryPack Option kit. A loose or poorly routed wiring
harness could interfere with option module (DRd-FLO or DRd-DALI) installation.
DRd enclosure before UBPO cable and
connector installation
DRd enclosure after UBPO cable and
connector installation
