ETC Unison DRd Dimming Rack Enclosure User Manual
Page 46
42
DRd Enclosure Installation Manual
The DALI option supports 64 DALI compatible devices per DALI loop. All DALI devices
connected to that loop will respond at the same time and to the same level as sent by the
broadcast command.
Step 1:
Align the DALI option board to the mounting studs in the bottom right side of the
enclosure.
•
Notice the mounting holes on the DALI option board. One is a slotted
keyhole, another is an open ended slot and the remaining two on the other
end of the board are standard mounting holes used to secure the board in
place.
Step 2:
Set the rear left stud through the slotted keyhole and align the open ended slot
with the back right side mounting stud.
Step 3:
Gently slide the DALI board toward the right I/O board aligning the five prong
connector to the receptacle on the I/O board.
Step 4:
Secure the bottom two mounting studs with the screws provided.
Step 2:
Step 3:
Step 4:
