10

Unison

®

ERn Wall Mount Enclosure Installation Manual

The following table lists the recommended control wire types used in a typical Unison

installation and the maximum wire runs allowed.

Data Types and Topologies

LinkConnect

LinkConnect is the station communication bus from the Architectural Control Processor to

the stations. LinkConnect is based on Echelon

®

LonWorks™ with LinkPower bidirectional

protocol, and uses one pair of wires (data +, data -). An additional 14 AWG (2.5mm

2

) wire

for grounding is required when not installed in grounded metal conduit.

ETC uses two types of LinkConnect networks, for SmartLink and Paradigm systems. While

the wiring for LinkConnect in SmartLink and Paradigm systems are the same, the two

communication and control types are not interchangeable. SmartLink products are

compatible only with the SmartLink ACP, SmartLink Station Power Module, and SmartLink

Architectural Control Stations. Paradigm products are compatible only with the Paradigm

ACP, Paradigm Station Power Modules, Unison Heritage Control Stations, and Paradigm

Touchscreens.

LinkConnect is topology-free and polarity independent, you can install your LinkPower data

runs in any desired combination of bus, loop, star, and home run. ETC recommends the

use of Belden 8471 (or approved equal) wire. The total combined length of a LinkPower

wire run cannot exceed 1,640 feet (500m) with a maximum distance of 1,312 feet (400m)

between any two devices.

DMX (Digital Multiplex)

DMX can address up to 512 channels of control. DMX is installed in a daisy chain topology

and includes one pair of wires (data+ and data-) plus ground. ETC recommends the use of

Belden 9729 (or approved equal) wire with a single end of line termination (90-150

 For

best DMX performance, twist the wires together as close to the pluggable connector as

possible. DMX devices manufactured by ETC are compliant with the USITT DMX512A

standard.

Auxiliary 24 Vdc

Auxiliary power is required when you are installing powered Unison control stations. ETC

recommends using two 16 AWG (1.5mm

2

) stranded wires for 24 Vdc auxiliary power to the

control station(s). Auxiliary power is topology-free. Maximum auxiliary voltage runs are

dependant by the wire gauge and the distribution of auxiliary load determined by

installation. The auxiliary supply is capable is of 36W (1.5A at 24Vdc).

Purpose

Stations

(Belden 8471)

DMX (Belden

9729)

Ethernet

(Cat5 /Belden

1583a)

Feet

Meter

Feet

Meter

Feet

Meter

Total length of control wire
(without repeater module)

1640

500

1600

487

328

100

Maximum wire length
(device to device)

1313

400

1600

487

N/A

N/A

Maximum repeater distance

1640

500

N/A N/A

N/A

N/A

N o t e :

Repeater modules may be used to extend the Unison LinkPower station data bus

an additional 1,640 feet (500m) total wire, with a maximum distance of 1,313 feet

(400m) between the repeater and any station or Station Power Module.
