Fixture components – ETC Source Four LED v1.6.0 User Manual User Manual
Page 9
Introduction
3
Fixture Components
Figure-1.1 Components of the Source Four LED Profile Fixture.
Figure-1.2 Components of the Rear Panel.
Figure-1.3 Keypad Button Functions.
For information about the user interface, see
User Interface Overview, page 32
Color frame
holder
Accessory
retainer
Safety
cable
loop
Yoke
Yoke
locking
knob
Power In
Power Thru
DMX In
DMX Thru
Status
indicators
LCD
Keypad
Light Bulb
Enter
Down
Up
Back
Home
