Operation 65
Recalibrate Fixture
Service technicians may use this option to calibrate the constant current driver electronics
for the LEDs. The calibration process goes through each series of LEDs, starting at 0
intensity and stepping up to 100%. The calibration is automatic and takes a few minutes.
During this time, do not exit the screen until it is complete.
Step 1: On the Diagnostics screen, scroll to Recalibrate Fixture.
Step 2: Press [ ].
Step 3: When asked if you are sure, select Yes and press [ ].
Figure-3.36 LED Calibration Screen with Calibration in Process.
Step 4: Press [ ] or [ ] to return to the Diagnostics screen.
About Fixture
The About screen displays the following information. This is a read-only screen.
• The software version number
• The fixture serial number
• The assigned fixture RDM number
• The color bias of the LED array
Figure-3.37 About Fixture screen.
Step 1: On the Diagnostics screen, scroll to About Fixture.
Step 2: Press [ ].
Step 3: Press [ ] or [ ] to return to the Diagnostics screen.
C A U T I O N : This calibration process does not measure or recalibrate the light output of the LEDs.
Under normal use, it is not necessary to recalibrate the fixture, and doing so will likely
have no beneficial effect on fixture performance. It is therefore NOT recommended
to recalibrate the fixture without express instruction from an authorized technician.
LED Calibration
LED 1 .......Pass
LED 2 .......Pass
LED 3 .......Pass
LED 4 .......Working
LED 5 .......Working
LED 6 .......Working
LED 7 .......Working
Diagnostics
Recalibrate Fixture
This Will Calibrate
LED Array
Are You Sure?
Yes
No
About Fixture
RDM: 6574:12345678
Ver: 1.5.0.0.0.05 (0)
Ser: 000021xxx
Desire Lustr+ 22
DMX START: 001
RDM Label
