Installation and User Interface

Step 1:

Secure the C-clamp to the yoke with the provided yoke bolt and lock washer.

Step 2:

Place the C-clamp on the mounting pipe and secure by tightening the pipe bolt.

Step 3:

Loosen the C-clamp pan screw and rotate the yoke to the desired position.

Step 4:

Retighten the pan screw to lock the fixture.

C A U T I O N :

Tighten C-clamp pipe bolt to 15-20 ft./lbs. (approximately finger tight plus up to

one-quarter turn). Do not exceed 25 ft./lbs. Do not use excessive force.
Tighten the yoke pivot bolt to 5-10 ft./lbs. (approximately finger tight plus up to

one-eighth turn). Do not exceed 15 ft./lbs. Do not use excessive force.
