Quick Setups (Daylight and Tungsten)
Step 1:
On the Main Menu, scroll to Quick Setups.
Step 2:
Press [
].
Step 3:
Scroll to the desired setup and then press [
].
An asterisk (*) next to the setup name indicates that setup is active.
Step 4:
Press [
] to return to the home screen.
The top line of the home screen displays the name of the active setup.
Studio Quick Setup
From the home screen:
•
To adjust the Intensity, press [
] or [
].
The range is 0 to 100%.
•
To adjust the White Point, press [
] or [
].
The range is 2700 to 6500K.
•
To adjust the Tint, press [
] & [
] or [
].
[
] increases magenta and [
] increases green.
•
To return to the Main Menu, press [
].
Advanced Settings
Step 1:
From the Main Menu press [
] to scroll to Advanced Settings.
Step 2:
Press [
].
Step 3:
Access the individual settings via additional menus.
Step 4:
Press [
] to return to the home screen.
Once you are familiar with your fixture, you may alter any of the numerous individual
settings from the Advanced Settings menu. For more information, see
Quick Setup
Description
Control
Channels
Features
Studio
Video or film:
The default setting for Daylight and
Tungsten fixtures.Studio Quick Setup
enables stand-alone operation from the
User Interface on the back of the fixture if
no console is present. For more
information, see
3 –
Intensity,
Strobe, Fan
Control
• Linear dimming curve
• Regulated output for brightness
consistency
• Strobe enabled
Stage
Theatrical lighting:
Behaves like a theatrical fixture in control
and dimming performance.
3 –
Intensity,
Strobe, Fan
Control
• Incandescent dimming curve
• Regulated output for brightness
consistency
• Strobe enabled
Single
Channel
Architectural installations:
Most streamlined settings for applications
with limited control options.
1 – Intensity
• Standard dimming curve
• Regulated output for brightness
consistency
• Automatic fan control
