46 Source Four LED Profile v1.6.0 User Manual
LED Settings
Use the LED Settings menu to adjust fixture performance. From the LED Settings menu,
you can set the following.
• Output
• Curve
• Output Frequency
• Red Shift
• White Point
Figure-3.10 Selecting LED Settings on the Advanced Menu.
Output
Use Output to choose the optimal balance between two competing performance
parameters, maximum brightness and output consistency, by adjusting:
• How much the fixture limits the overall power to the LED array.
• How the fixture reduces output as internal fixture components heat up during use or in
high ambient temperatures.
The output options are as follows.
Regulated
Regulated is a moderately constrained power or brightness with consistent output under
typical use. Power to the LEDs is separately regulated in order to maintain consistent
brightness during the initial fixture warm-up period. This is recommended for most indoor
applications.
Protected
Protected provides the most consistent output possible with the greatest potential for
reduced overall brightness. This is best for changing environmental temperatures, and
applications with high requirements for consistency in extreme operating conditions.
Boost
Boost provides the brightest possible output, with least guarantee of consistency. This is
best for applications with low duty cycles, loose brightness requirements, or where ambient
temperature is low.
LED Settings
Output : Regulated
Curve: Standard
Output Freq:
1200
Red Shift: Off
White Point: 3200K
Advanced Menu
DMX Settings
LED Settings
Presets and Sequences
Diagnostics
Local Settings
Copy All Settings
