Source Four LED Profile v1.6.0 User Manual
Specifications
Physical
• Rugged die-cast aluminum construction
• Hanging yoke standard
• Easy-access slots for secondary lenses and standard
accessories.
• Available in black (standard), white (optional), silver, or
custom colors (contact factory)
• Advanced thermal management systems for long LED
life
• Features ultra-quiet cooling fan
• Ambient operating temperature
0 to 40 °C (32 to 104 °F)
• See
• Continuous operation at 40 °C (104 °F)
Electrical
• 100V to 240V 50/60 Hz universal power input
• 5 foot Neutrik PowerCon to bare-end power input lead
or parallel blade U-ground (Edison) connector
• Includes Neutrik
®
PowerCon
®
in and thru connectors
• Optional 5 foot PowerCon to 20A two pin and ground
(stage pin) or grounded 20A twistlock connector
• No more than nine total Source Four LED (four total
Series 2 Lustr) fixtures on Power Thru
• Requires power from non-dim source
LEDs
• 60 Luxeon
Rebel LED emitters (Lustr+ and Series 2
Lustr)
• 60 Luxeon
Rebel ES LED emitters (Daylight and
Tungsten)
• 33 Osram OSLON Square and 27 Luxeon Rebel LEDs
(Studio HD)
• See
Note About LED Fixtures, page 10
• 50,000 hr. LED life
• 20,000 hr. LED life (Series 2 Lustr)
Optical
• Compatible with all ETC Source Four lens tubes. For
best results, use the preferred lens tubes. See
Preferred Lensing Options, page 12
Control
• DMX512-A compliant
• Optional strobe channel
• DMX in and thru via 5-pin XLR connectors
• Standalone, studio standalone, and console-free
presets and sequences
• Onboard user interface with a high-resolution LCD
• Master/slave mode
• Multiple profile options for different levels of control
• 15-bit virtual dimming engine for smooth, high-quality
theatrical fades
• Optional DMX-based fan control for predictable noise
levels
• See
