26 Source Four LED Profile v1.6.0 User Manual
RGB
Effectively addresses all seven colors via three channels of control. The RGB profile
produces medium-quality color crossfades. It makes the Source Four LED Profile fixtures
compatible with conventional RGB console profiles while maintaining enhanced color
production from the fixture. Also see Color Matching, page 27
.
Studio
The fixture produces only white-type light, which is adjustable from 2700 to 6500K. The
Studio profile uses three DMX channels to control Intensity, white point, and tint. Tint is
adjustable without affecting the white point. All three control parameters are adjustable via
DMX as well as onboard with instant access via UI buttons.
For more information, see Studio Settings, page 70 . Also see Color Matching, page 27 .
Data Channel Control Value Function
1 Fixture address Red
0 to 255 Intensity 0 to 100% 2 Fixture address + 1 Green
3 Fixture address + 2 Blue
4 Fixture address + 3 — — —
5 Fixture address + 4 Strobe
0 to 255
Variable strobe control
6 Fixture address + 5 Fan control
Force fan on various
speeds
N o t e : The RGB profile is optimized for maximum brightness at all settings. Occasionally
small changes in RGB values may produce unexpected jumps in brightness.
Shifts in brightness may be perceived during color crossfades in cues and presets.
Data Channel Control Value Function
1 Fixture address Intensity
0 to 255
Intensity 0 to 100%
2 Fixture address + 1 White point: 2700 to 6500K
0 = 3200K
1 to 254 = 2700K to 6500K
255 = 5600K
3 Fixture address + 2 Tint
0 = neutral white
1 to 127 = full plus-green
to neutral white
128 = neutral white
129 to 255 = neutral white
to full minus-green (full
magenta)
4 Fixture address + 3 — — —
5 Fixture address + 4 Strobe
0 to 255
Variable strobe control
6 Fixture address + 5 Fan control
Force fan on various
speeds
