Page 66: N o t e
60
Source Four LED Profile v1.6.0 User Manual
Quick Color (Lustr+, Series 2 Lustr, Studio HD)
Quick Color allows you to easily select a color and its intensity from a predefined menu.
This feature overrides any presets or sequences previously selected and is only available
when there is no external DMX signal to the fixture. For a list of available colors, see the
table on
.
To select a Quick Color:
Step 1:
Scroll to Quick Color within the Presets and Sequences screen.
Step 2:
Press [
].
Figure-3.29 Selecting Quick Color on the Presets and Sequences Menu.
Step 3:
Scroll to Color and press [
].
Step 4:
Press [
] or [
] to select the desired color
Step 5:
Press [
] to commit the selection.
Step 6:
Scroll to Intensity and press [
].
Step 7:
Press and hold [
] or [
] to adjust the fixture’s intensity.
Step 8:
Press [
] to commit the selection.
•
To set the Intensity to 0, press the [
]. Pressing [
] a second time will
return the fixture to its previously set Intensity.
•
If power to the fixture is lost while in Quick Color mode, the fixture will return
to the Quick Color menu once power is restored.
Master/Slave Operation
When similar fixtures' DMX or data connections are linked together and there is no external
DMX signal going to them, one fixture automatically controls all other fixtures in the chain
when a Preset or Sequence is initiated.
Master
Master is the one fixture that controls all fixtures in the daisy chain. By default, it is
whichever fixture had its Preset or Sequence selected or adjusted most recently. The
Master fixture can only control Slave fixtures to produce identical output at the same time
as itself. The Master fixture cannot control Slave fixtures to operate individually or to run
chase-type or time-offset sequences.
Changes and edits to Presets or Sequences that are made to the Master fixture may be
copied to the internal memory of all Slave fixtures for later use when these fixtures are
disconnected from the data daisy chain.
N o t e :
Exiting the Quick Color menu will return the fixture to the state it was in before
entering the menu.
Presets and Sequences
Focus: Off
Presets
Sequences
Quick Color
Preset 1 is Active
No Sequence is Active
Quick Color
Intensity
:
100%
Color:
–––
