Page 24

Source Four LED Profile v1.6.0 User Manual

Adjusting the Yoke Position

The Source Four provides multi-positioning capabilities within its yoke for overall fixture height and

angle.

Setting the Fixture Height Within the Yoke

The Source Four has a two-position yoke for modifying the overall mounting height.

Figure-1.10 Adjusting the yoke position.

To change the fixture yoke position:

Step 1:

Remove the yoke locking knobs, washers, and hex bolts from either side of the

fixture.

Step 2:

Raise or lower the fixture to the desired position within the yoke.

Step 3:

Reinstall the yoke’s hex bolts, washers, and locking knobs.

Step 4:

Tighten the yoke knobs to secure in position.

Low clearance position

General use position
