Inhibit Active. This bit indicates that the gateway relays and display
are inhibited from responding to changes in the communication mod-
ule’s status. The Inhibit Active status is controlled by the “Inhibit” button.
Sensor Fault. This bit is set when the gas level is below the fault
threshold or the Invalid Configuration bit is set.
Invalid Configuration. This bit indicates that configuration informa-
tion is invalid and is set on a new unit, when the address is changed,
or when invalid data is transferred. A valid configuration must be down-
loaded to clear the bit.
Digital Input 1/2. This indicator shows the status of the signal con-
nected to the communication module’s digital input.
Output Relay. This bit is set when the communication module’s output
relay is activated.
C
ALIBRATION
I
NFORMATION
In Calibration. This bit is active during the sensor calibration proce-
dure.
Calibration Fault. This bit is set when a fault is detected during the
calibration procedure.
Calibration History. The communication module stores the baseline
and the last seven calibration records (date, time, high and low cali-
bration values). These records allow the operator to spot trends in sen-
sor sensitivity or potential problems. Clicking in the calibration history
box will bring up a graphic representation of the calibration history.
A
LARM
I
NFORMATION
High and Low Alarm. The alarm indicator is on when the gas con-
centration exceeds the alarm setpoint and clears when the level returns
below the setpoint. The current alarm setpoint values are also displayed.
The alarm setpoint values are selected on the point configuration screen.
Alarm History. The communication module stores and displays the
last eight alarms (high and low). The display includes the type of alarm
and the time and date stamp.
U
PDATE
R
ATE
This field shows in milliseconds how often the communication module
will report its status to the gateway. The update rate is programmable
from 1 to 10 seconds on the communication module configuration
screen.
