Point display screens provide detailed status information for each con-
figured point on the network. Information provided on the point display
screens includes:
• current analog value (displayed as bar graph and in engineering
units)
• alarm setpoint levels
• communication status
• sensor status
• relay status
• calibration status and history
• alarm status and history.
All point display screens share the following common fields.
Point Name is displayed in the upper left hand corner of the screen.
LON Name and Point Number are displayed in the upper right
hand corner of the screen.
Goto Point, Next Point and Previous Point buttons allow the
operator to navigate from one point to another.
Inhibit button toggles the status of the inhibit bit. When a point is inhib-
ited, the gateway relays and display are inhibited from responding to
changes in the status of this point.
Close button closes this screen and returns to the previously displayed
screen.
Status Indicators are normally black and turn red when active. In a
properly operating system with no faults or alarms occurring, all indi-
cators are off with the exception of the LON Master indicator on the
Gateway Point Display screen.
From the Point Configuration screen, highlight the gateway, then click
on Display Point or select Point from the View menu. The Gateway Point
Display screen will be displayed. See Figure VIII–1.
95-8479
8.1
E
AGLE
2000 P
OINT
D
ISPLAYS
C
OMMON
D
ISPLAY
F
IELDS
G
ATEWAY
P
OINT
D
ISPLAY
