Low Battery — battery voltage is out of tolerance.
Battery Test Active — feature is not supported.
CPU Reset — status is activated for 60 seconds when the board is
reset from power-up, by the watchdog timer, or by pressing the reset
switch on the board.
Battery Current Ma — less than one ampere of current is flowing
between the power supply and batteries.
No Battery Test — too soon to conduct a battery test.
Not Communicating — board is not responding.
Local Hardware.
See Figure VII–7. The Local Hardware display shows the current state of
the logic controller’s hardware.
Normal, Enable, Program and Isolate — current status of the
faceplate key switch.
Ground Fault and LON Ground Fault — faults detected by the
LON Isolator module.
Ack Switch and Silence Switch — these bits track the status of the
pushbutton switches on the logic controller faceplate.
Alarm Relay, Trouble Relay and Supervisory Relay — these
bits track the current status of the relays.
7.10
E
AGLE
Q
UANTUM
P
OINT
D
ISPLAYS
FIGURE VII-7
Logic Controller
Local Hardware
Point Display Screen
