The purpose of this manual is to describe the logic generation tools and
their uses, not programming techniques. Only fully qualified and trained
personnel should attempt logic generation.
There are 14 types of logic elements available for use in any order or
combination desired.
Each logic page can have up to 32 logic elements.
Every element placed on the screen with the exception of connecting
lines and descriptive text are counted against the 32 possible elements
on a page.
The basic sequence for creating logic is as follows:
1. Place input gates on the page and configure them. To configure a
gate, double click on the gate and select the appropriate parame-
ters from the gate edit screen.
2. Place logic gates on the page and connect to the appropriate
inputs.
5.26
E
AGLE
Q
UANTUM
S
YSTEM
C
ONFIGURATION
FIGURE V-18
Page Information Screen
