2. Select “Copy” from the Edit menu.
3. Highlight the address or group of contiguous addresses where the
configuration data will be pasted, then select Paste from the Edit
menu. All of these addresses will now be configured with the iden-
tical data as the first address.
4. Sequentially select each of the new addresses, click on modify
point, assign a tag name to the point, and modify any other con-
figuration data as desired.
EagleVision-NT allows the creation of custom logic using standard gate
logic symbols. This logic is then downloaded through the Gateway to
the Logic Controller. The system supports up to 32 pages of custom
logic, each page containing up to 32 logic elements.
This software should be used only by qualified personnel. Operators
should have experience and knowledge of gate logic programming.
Contact Detector Electronics Corporation for information on upcoming
training.
P
ROJECT
T
ASKS
1. Define and Configure Field Devices.
Configure the type and operating parameters for each of the
devices on the LON/SLC.
2. Local Input/Output Unit (LIOU) Configuration.
Configure the type and operational parameters of the I/O cards that
are installed in the LIOU following the instructions discussed under
“LIOU Configuration.”
3. Network Variable Configuration.
Configure the logic controller to recognize the devices on the
LON/SLC that will be used by the programmable logic. This is a
part of the supervision mechanism to ensure the integrity of the sys-
tem.
4. Logic Development.
Use the logic tools to create custom logic.
5. Logic Tests.
Download the custom logic to the logic controller, verify its opera-
tion, then write the logic to EEPROM in the Logic Controller.
6. Logic Documentation.
Print out the logic pages for a permanent record.
5.24
E
AGLE
Q
UANTUM
S
YSTEM
C
ONFIGURATION
C
USTOM
L
OGIC
