Det-Tronics EagleVision - PC User Manual
Page 71

Invalid Configuration. This bit indicates that configuration informa-
tion is invalid and is set on a new unit, when the address is changed,
or when invalid data is transferred. A valid configuration must be down-
loaded to clear the bit.
Auto Config Fault. This bit indicates that the gateway was unable to
successfully download configuration information.
I
NPUT
1 / I
NPUT
2
The open indicator turns on if the input is not properly terminated, if a
wire is open, or if the device being monitored is in fault.
The active indicator turns on when the input circuit is closed.
The mode field shows how the input is configured — Alarm, Trouble,
Supervisory, or other. This can be changed on the IDC configuration
screen.
S
WITCHES
This area shows the current status of the four DIP switches on the IDC
CPU board.
A
LARM
A
DDRESSES
This area shows the addresses of the logic controllers that are config-
ured for communication with this IDC. All alarm and trouble status infor-
mation will be sent to the addresses listed here. The addresses can be
changed on the IDC configuration screen.
I
NPUT
H
ISTORY
The IDC stores the time, date, and input type of the last eight activations.
This information is displayed by clicking on the Fetch Logs button.
U
PDATE
R
ATE
This field shows in milliseconds how often the IDC will report its status
to the gateway. The update rate is programmable from 1 to 10 seconds
on the IDC configuration screen.
F
ETCH
L
OGS
B
UTTON
This button will retrieve the input activation logs.
7.14
E
AGLE
Q
UANTUM
P
OINT
D
ISPLAYS
