name and clicking on the Events or Alarm button enables or disables
the event or alarm log control bit in the Wonderware db.CSV export
file. The Event or Alarm priority value will also be exported.
To select tagnames, hold the Shift key and click on the tagnames.
Then click on either the Events or Alarm button. Tagnames will be
color coded on the Edit Triggers screen as follows:
Alarms = Red, Events = Blue, Off = Black.
Enter the desired priority level (0 to 999) in the “Event” and “Alarm”
boxes located in the upper right hand corner of the screen.
8. Click on Close to return to the Select Triggers Form screen.
9. Click on Close to return to the Point Configuration screen.
P
RINTING
T
RIGGER
D
ATA
To obtain a permanent record of trigger information for the system, from
the Select Triggers screen select Print under the File menu. EagleVision-
NT will print a list of trigger data for all devices in the system. This
includes both factory default triggers and custom triggers. Printed infor-
mation includes the type and name for each trigger as well as a com-
plete listing of all events configured under the categories of alarm, trou-
ble and other.
G
ATEWAY
C
ONFIGURATION
Addresses 1 through 4 are reserved for gateways only. Address num-
ber 1 should be used for the main gateway and 2 to 4 for auxiliary
gateways (if used).
1. Highlight line 1 on the Point Configuration screen. Click on the
Modify Point button.
2. Click on the Define button. Select the gateway type, then click on
OK. The Gateway Configuration screen will be displayed. See
Figure V–3.
95-8479
5.3
E
AGLE
Q
UANTUM
S
YSTEM
C
ONFIGURATION
LCU C
ONFIGURATION
