AND Gate
Eight input logical “AND” gate.
To place an AND Gate, select this tool, then click on the location where
it will be placed.
Unused inputs are evaluated as a “1.”
OR Gate
Eight input logical “OR” gate.
To place an OR Gate, select this tool, then click on the location where
it will be placed.
Unused inputs are evaluated as a “0.”
NOT Gate
Logical inverter. A “1” in = a ”0” out.
To place a NOT Gate, select this tool, then click on the location where
it will be placed.
Less Than Gate
Less than “n” gate. Accepts a single integer input from a Binary Adder
or Integer Counter, compares it to “n” and creates a binary output.
To place a Less Than Gate, select this tool, then click on the location
where it will be placed. To assign a value to “n,” double click on the
gate, then enter the value in the Preset box.
Greater Than Gate
Greater than “n” gate. Accepts a single integer input from a Binary
Adder or Integer Counter, compares it to “n” and creates a binary out-
put.
To place a Greater Than Gate, select this tool, then click on the location
where it will be placed. To assign a value to “n,” double click on the
gate, then enter the value in the Preset box.
Equals Gate
Accepts a single integer input from Binary Adder or Integer Counter,
compares it to “n” and creates a binary output.
