The Logic Controller occupies two adjacent addresses. When con-
figuring a Logic Controller, it must be assigned an odd address. It
will then automatically use the following even address. A Logic
Controller can be assigned any address from 5 to 249, however,
address number 5 is recommended. (If additional Logic Controllers
are used, they should be assigned to Addresses 7, 9, etc.)

2. Type a tag name for the point in the space provided.

3. Assign a trigger for the point.

4. The Logic Controller communicates over the network with input

devices such as flame detectors, DCUs, and IDCs, and output
devices such as SAMs and ARMs, as well as all devices in the LIOU.
The remainder of the Logic Controller configuration will be covered
in connection with the configuration of those devices later in this
manual.

5. Click on Accept. Click on Close to exit and return to the Point

Configuration screen, or use the scroll arrows to select the next point
for configuration.

DCU C

ONFIGURATION

To configure a DCU with combustible gas sensor, O2 sensor, or
PointWatch:

1. Highlight the desired address on the Point Configuration screen.

Click on the Modify Point button.

2. Click on the Define button.

3. Click on the appropriate button for the type of device being config-

ured, then click on OK. The DCU Configuration screen will be dis-
played. See Figure V–5.

95-8479

5.7
