L

OGIC

P

AGE

I

NFORMATION

From the Logic Controller Configuration screen (Figure V–4), click on the
Logic button. The Logic screen is displayed. See Figure V–17.

A variety of information can be entered for each logic page, including
title, date, revision etc. Select Page Information under Edit. The Page
Information screen appears. See Figure V-18. Complete the fields as
necessary for each logic page.

95-8479

5.25

E

AGLE

Q

UANTUM

S

YSTEM

C

ONFIGURATION

FIGURE V-17

Logic Screen
