IT Infrastructure RAP/RAC1000

OUTER

The IP router option divides the networks in two separate networks between LAN-in and

LAN-out interface and filters them separately.

WLAN / Host interface:
IP assignment for the LAN-in interface can be made in two different ways:
Static:
If this option is selected, a permanently assigned IP address may be entered.
Static IP-address assignment requires that the IP address and the subnet mask is entered.
The default values are:
IP address: 192.168.0.254
Subnet mask: 255.255.255.0
DHCP:
The DHCP function requests an IP address from a DHCP server and assigns it automatically
to the firewall.
DHCP with fallback address:
This option is a combination of static and automatic IP-address assignment. If an error
occurs during automatic address assignment of the DHCP server, or if no DHCP server is

available, IP assignment automatically switches to the entered static IP address.
