8.10.3
H
ARDWARE INSTALLATION
1)
Installation bracket (for mounting the Access Point in the place of installation)
2)
Antennas
3)
Service compartment
4)
Interfaces
5)
Status displays
8.10.4
L
OCAL DIAGNOSTICS
The Local diagnostics page shows the LED display functions with different system activities.
