IT Infrastructure RAP/RAC1000
154
© ads-tec GmbH • Raiffeisenstr.14 • 70771 Leinfelden-Echterdingen
9.4 5 GHZ DFS REGULATION
AFTER
ETSI EN 301 893 V1.4.1 WITHIN THE EU
I NDOOR C HANNELS :
Channel Number
1)
Frequency
(MHz)
Max. permissible.radiation with TPC
36 5.180 23 dBm
40 5.200 23 dBm
44 5.220 23 dBm
48 5.240 23 dBm
1) Can be configured manually, DFS is not activated. TPC is always active on ads-tec
devices at 5 GHz.
O
UTDOOR C HANNELS :
Channel Number
2)
Frequency
(MHz)
Max. radiation with TPC DFS latency
3)
52 5.260 23 dBm 1 min.
56 5.280 23 dBm 1 min
60 5.300 23 dBm 1 min
64 5.320 23 dBm 1 min
100 5.500 30 dBm 1 min
104 5.520 30 dBm 1 min
108 5.540 30 dBm 1 min
112 5.560 30 dBm 1 min
116 5.580 30 dBm 1 min
120 5.600 30 dBm 10 min
5)
124 5.620 30 dBm 10 min
5)
128 5.640 30 dBm 10 min
5)
132 5.660 30 dBm 1 min
136 5.680 30 dBm 1 min
140 5.700 30 dBm 1 min
2) Can only be selected automatically. DFS is always activated. TPC is always active on
ads-tec devices at 5 GHz.
3) The DFS latency is actively waiting on power, as well as channel change by radar
detection.
4) Access Clients can work without own DFS, if they stay at a permissible radiation of
23dBm. For ads-tec Access Clients, DFS can be activated like the Access Points to a
permissible radiation of 30dBm with TPC.
5)5.6 Ghz Weather Radar Channels at ads-tec Access Points have to be activated
separately.
