IT Infrastructure RAP/RAC1000

196

ONFIGURATION OF

ORT

ORWARDING

Under Configuration  Network  Port Forwarding, rules can be defined for forwarding
the inbound Ethernet packets. Thus it is possible to directly address the „disguised“

terminal from the WLAN network (10.0.0.0) without knowing its IP address.

The first rule is to redirect all http enquiries (Port 80) to the WLAN Client itself; thus its

web interface can be addressed in the usual way.

Only the second rule forwards all residual packets (TCP and UDP) of all the other ports to
the terminal (192.168.0.1).

Note:
With these settings, it is not possible to access a web server at the terminal. If this is

required, the first rule has to be removed.
