42
2N TELEKOMUNIKACE a.s., www.2n.cz
®
Figure: Address Configuration for Audio Unit – Cabin Universal
Bus Connection
Polarity must be maintained.
Note
Make sure that two audio units do not have an identical address to avoid
system error.
The position-setting jumpers are employed exceptionally, e.g. where a
certain audio unit type is used in a position other than normally intended.
To recover the initial address setting, follow the drawing on the cover.
