Basic Settings

The Basic settings menu provides basic information on the state of the device
connected:

FW version, serial number, voice menu language and time. The Time in

device parameter displays the current time read from the

. This parameter is not

read online and has to be updated using the Read from device parameter. Set time in
device helps you record a time setting of your own. Click on the calendar to set the
date/time in hours manually. This value can be overwritten and different time can be
set for a different time zone. Click Confirm to confirm the new setting. Click Save
current time from PC to device to synchronise the

time with your PC time value and

load the new setting into the

The Password section helps you change the administrator password for the

connect

ed. Enter the existing password into the Current password and the new password into
the New password. Click Save password to device to confirm and save the new setting.

Connected Units

The Connected units menu provides a graphic diagram of all the units connected to 2N

The following controls are available: Refresh to update the display, Press HW

Lift8.

setting (diagram/text) to print out the diagram/text of all the Audio Units and splitters
connected to the given CU. The diagram displays the units like in the application and
the text provides the same information as the diagram in the XML format. Click these
buttons to export the diagram/text to the printer. Zoom in and Zoom out help you get
a closer (more detailed) and more distant view (whole structure) of the diagram/text
respectively.

Diagram of Connected Units

The diagram displays graphically all the devices connected to the selected

: buses,

shafts and Audio Units. Tick off the checkboxes in the Unit description to display details
on the Audio Units and select the Audio Unit type as shown in the figure below. The
brief description to the left of the Audio Unit includes the Audio Unit serial number,
type and current state.

Note

Remember to change the password in the

2N Lift8

Service Tool

configuration too for future connections.
