SECTION 6 - JLG CONTROL SYSTEM
3121180 – JLG Lift – 6-77
REAR LEFT WHEEL BLOCKED Wheel not responding to steer commands. Fault clears when condition clears.
REAR RIGHT WHEEL BLOCKED Wheel not responding to steer commands. Fault clears when condition clears.
FRONT LEFT WHEEL SENSOR OUT
OF RANGE LOW Steering angle sensor short to ground or open circuit detected.
FRONT LEFT WHEEL SENSOR OUT
OF RANGE HIGH Steering angle sensor short to battery detected.
FRONT RIGHT WHEEL SENSOR OUT
OF RANGE LOW Steering angle sensor short to ground or open circuit detected.
FRONT RIGHT WHEEL SENSOR OUT
OF RANGE HIGH Steering angle sensor short to battery detected.
REAR LEFT WHEEL SENSOR OUT OF
RANGE LOW Steering angle sensor short to ground or open circuit detected.
REAR LEFT WHEEL SENSOR OUT OF
RANGE HIGH Steering angle sensor short to battery detected.
REAR RIGHT WHEEL SENSOR OUT
OF RANGE LOW Steering angle sensor short to ground or open circuit detected.
REAR RIGHT WHEEL SENSOR OUT
OF RANGE HIGH Steering angle sensor short to battery detected.
8/7 Flash code 8/7 indicates new main angle sensors 10
NEW MAIN ANGL1 SENSOR
DETECTED System detected a different main angle #1 sensor than it was calibrated with.
(1250AJP only.)
NEW MAIN ANGL2 SENSOR
DETECTED System detected a different main angle #2 sensor than it was calibrated with.
(1250AJP only.)
Table 6-8. Help Fault Codes, Displayed Faults, and Descriptions - S/N 0300066949 & S/N 1300000001 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
