SECTION 6 - JLG CONTROL SYSTEM
6-64 – JLG Lift – 3121180
HEAD TAIL LIGHT OPEN CIRCUIT Machines with headlights option configured ONLY
HEAD TAIL LIGHT SHORT TO BAT-
TERY Machines with headlights option configured ONLY
BASKET UP OVERRIDE SHORT TO
GROUND Machines with electronic leveling systems ONLY.
BASKET UP OVERRIDE OPEN CIR-
CUIT Machines with electronic leveling systems ONLY.
BASKET UP OVERRIDE SHORT TO
BATTERY Machines with electronic leveling systems ONLY.
BASKET UP SHORT TO GROUND
BASKET UP OPEN CIRCUIT
BASKET UP SHORT TO BATTERY
BASKET DOWN SHORT TO GROUND
BASKET DOWN OPEN CIRCUIT
BASKET DOWN SHORT TO BATTERY
BASKET DOWN OVERRIDE SHORT
TO GROUND Machines with electronic leveling systems ONLY.
BASKET DOWN OVERRIDE OPEN
CIRCUIT Machines with electronic leveling systems ONLY.
BASKET DOWN OVERRIDE SHORT
TO BATTERY Machines with electronic leveling systems ONLY.
TOWER LIFT APU VALVE STUCK
OPEN 1250AJP ONLY.
TOWER LIFT ENABLE STUCK OPEN 250AJP ONLY.
TOWER LIFT ENABLE SHORT TO
GROUND 250AJP ONLY.
TOWER LIFT ENABLE OPEN CIRCUIT 250AJP ONLY.
TOWER LIFT ENABLE SHORT TO
BATTERY 250AJP ONLY.
TOWER TELESCOPE APU SHORT TO
GROUND 250AJP ONLY.
TOWER TELESCOPE APU OPEN CIR-
CUIT 250AJP ONLY.
TOWER TELESCOPE APU SHORT TO
BATTERY 250AJP ONLY.
BASKET LEFT OPEN CIRCUIT
BASKET LEFT SHORT TO BATTERY
BASKET LEFT SHORT TO GROUND
BASKET RIGHT SHORT TO GROUND
BASKET RIGHT OPEN CIRCUIT
BASKET RIGHT SHORT TO BATTERY
JIB UP SHORT TO GROUND
JIB UP OPEN CIRCUIT
JIB UP SHORT TO BATTERY
JIB DOWN SHORT TO GROUND
Table 6-8. Help Fault Codes, Displayed Faults, and Descriptions - S/N 0300066949 & S/N 1300000001 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
