SECTION 6 - JLG CONTROL SYSTEM
3121180
– JLG Lift –
6-51
osc axle p sw
OP/CL
Oscillating axle pressure switch status. (Displayed if
OSCILLATING AXLE = 1)
sky welder
YES/NO
Status of Sky Welder selected during boom sensor calibration.
(Displayed if MODEL NUMBER = 7 or 8)
sky cutter
YES/NO
Status of Sky Cutter status selected during boom sensor calibra-
tion. (Displayed if MODEL NUMBER = 7 or 8)
sky glazier
YES/NO
Status of Sky Glazier selected during boom sensor calibration.
(Displayed if MODEL NUMBER = 7 or 8)
sky Bright
YES/NO
Status of Sky Bright selected during boom sensor calibration.
(Displayed if MODEL NUMBER = 7 or 8)
Pipe Racks
YES/NO
Status of Pipe Racks selected during boom sensor calibration.
(Displayed if MODEL NUMBER = 7 or 8)
Camera mount
YES/NO
Status of Camera Mount selected during boom sensor calibra-
tion. (Displayed if MODEL NUMBER = 7 or 8)
LOAD:
Not displayed if LOAD=NO, LENGTH=NO, and ANGLE=NO
(machine digits = 0)
LENGTH
OP /CL
Measured length, Not displayed if MODEL NUMBER = 7 or 8
ANGLE
OP / CL
Measured angle, Not displayed if MODEL NUMBER = 7 or 8
WEIGHT
XXXX%
Percentage of maximum calibrated weight on the platform. An
uncalibrated load cell reads 1000% Displayed if LOAD is not 0 and
LOAD TYPE is 0.
OK/OVERLOADED
LSS system status. Displayed if LOAD is not 0 and LOAD TYPE is
1.
Table 6-6. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter (Displayed
on Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2
nd
Line)
Description
