SECTION 6 - JLG CONTROL SYSTEM
6-50 – JLG Lift – 3121180
HI TILTED - NO/YES Displays status of hi tilt input. (Displayed if external tilt sensor is
configured)
AUX POWER OP/CL Displays the status of the auxiliary power switch input
HORN OP/CL Displays the status of the horn input
R FILTER OP/CL Displays the status of the return hydraulic filter by-pass switch.
Displayed ONLY if MODEL = 600 (Configuration digit = 3)
C FILTER OP/CL Displays measured status of charge pump filter bypass switch.
Displayed ONLY if MODEL = 600 (Configuration digit = 3)
JIB BLOCK OP/CL Jib block limit switch status. Not displayed if associated configura-
tion digit = 0
BASKET STOWD YES/NO Status of basket stowed mode. (Displayed if MODEL NUMBER =
7 or 8)
SOFT LIMIT OP/CL Status of soft touch limit switch. Not displayed if associated con-
figuration digit = 0
SOFT O/R OP/CL Status of soft touch override switch. Not displayed if associated
configuration digit = 0
GEN SET/WELDER OP/CL Generator/welder switch input status. Not displayed if associated
configuration digit = 0
LIGHTS OP/CL Head and tail light switch input status. Not displayed if associated
configuration digit = 0
BSK TILT1 XX.X Indicated platform tilt angle. Displayed on models equipped with
Electronic Platform Leveling.
BSK TILT2 XX.X Indicated platform tilt angle. Displayed on models equipped with
Electronic Platform Leveling.
AXLE RET SW OP/CL Status of axle extension user switches. (Displayed if MODEL
NUMBER = 7 or 8)
AXLE EXT SW OP/CL Status of axle retraction user switches. (Displayed if MODEL
NUMBER = 7 or 8)
AXLE LIM SW RET/EXT Status of axle extension limit switches. (Displayed if MODEL
NUMBER = 7 or 8)
DOS LIM SW OP/CL Drive Orientation System Limit Switch status. (Displayed if
MODEL NUMBER = 7 or 8)
DOS O/R SW OP/CL Drive Orientation System Override switch status. (Displayed if
MODEL NUMBER = 7 or 8)
CAPACITY SW 500/1000 Capacity selection switch status. (Displayed if MODEL NUMBER
= 7 or 8)
Table 6-6. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter (Displayed
on Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2 nd
Line)
Description
