SECTION 1 - SPECIFICATIONS
3121259 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
1.2 TIRES
1.3 ENGINE
NOTE: RPM Tolerances are ± 100.
Table 1-1. Capacities
Fuel Tank 17 gallons (64.3 liters)
Hydraulic Tank
(machines to S/N 0300070586)
28 gallons (106 liters)
Hydraulic Tank
(S/N 0300070586 &
SN 1300000001to Present) 27 gallons (102 liters)
23.6 gal. (89 liters) to the Full line
on the sight gauge
Drive Hub 23.75 oz. (0.7 liters)
Drive Brake 2.7 oz. (0.08 liters)
Table 1-2. Tires
Size Type Pressure Weight
12x16.5 Pneumatic 90 psi (6 Bar) 128 lbs. (58 kg)
12x16.5 Foam-Filled N/A 328 lbs. (149 kg)
33/1550x16.5 Pneumatic 90 psi (6 Bar) 135 lbs. (61 kg)
33/1550x16.5 Foam-Filled N/A 395 lbs. (179 kg)
14 x 16.1 Pneumatic 40 lbs. (3 bar) 91.5 lbs. (41.5 kg)
14 x 16.1 Foam-Filled N/A 426 lbs. (193 kg)
Table 1-3. Ford LRG-425 (Gas or Dual Fuel)
Type 4 cylinder, 4 stroke, spark ignition
Fuel Gasoline or Gasoline/LP Gas
Bore 3 in. (96 mm)
Stroke 3.4 in. (86.4 mm)
Displacement 153 cu. in. (2.5 L)
Firing Order 1-3-4-2
BHP at Max. RPM 82
Oil Capacity 4.5 quarts (4.26 L)
Low RPM 1000
Mid RPM
Tower Lift, Upper Lift, Tele
Swing, Basket Level, Basket
Rotate, Jib Lift
1800
1500
High RPM 3000
Spark Plug AWSF-52-C
Spark Plug Gap 0.044 in. (1.117 mm)
Table 1-4. Deutz F3M1011F
Fuel Diesel
No. of Cylinders 3s
Bore 3.6 in. (91 mm)
Stroke 4.4 in. (112 mm)
Displacement 133 cu. in. (2184 cm³)
BHP at Max. RPM 48
Oil Capacity
crankcase
cooler
total capacity
6.3 quarts (6 L)
4.75 quarts (4.5 L)
11 quarts (10.5 L)
Low RPM 1200
Mid RPM
Tower Lift, Upper Lift, Tele
Swing, Basket Level, Basket
Rotate, Jib Lift
1800
1500
High RPM 2800
Table 1-5. Deutz F3M2011F
Fuel Diesel
No. of Cylinders 3s
Bore 3.7 in. (94 mm)
Stroke 4.4 in. (112 mm)
Displacement 142 cu. in. (2331 cm³)
Oil Capacity
crankcase
cooler
total capacity
6.3 quarts (6 L)
4.75 quarts (4.5 L)
11 quarts (10.5 L)
Low RPM 1200
Mid RPM
Tower Lift, Upper Lift, Tele
Swing, Basket Level, Basket
Rotate, Jib Lift
1800
1500
High RPM 2800
