SECTION 6 - JLG CONTROL SYSTEM
6-66 – JLG Lift – 3121180
LIFT DOWN AUX VALVE OPEN CIR-
CUIT Machines with gravity lift down ONLY.
TOWER LIFT APU SHORT TO
GROUND 1250AJP ONLY.
TOWER LIFT APU OPEN CIRCUIT 1250AJP ONLY.
TOWER LIFT APU SHORT TO BAT-
TERY 1250AJP ONLY.
MAIN LIFT ENABLE SHORT TO
GROUND 1250AJP ONLY.
MAIN LIFT ENABLE OPEN CIRCUIT 1250AJP ONLY.
MAIN LIFT ENABLE SHORT TO BAT-
TERY 1250AJP ONLY.
TOWER TELE APU VALVE STUCK
OPEN 1250AJP ONLY.
TOWER TELE ENABLE STUCK OPEN 1250AJP ONLY.
TOWER TELE APU SHORT TO
GROUND 1250AJP ONLY.
TOWER TELE APU OPEN CIRCUIT 1250AJP ONLY.
TOWER TELE APU SHORT TO BAT-
TERY 1250AJP ONLY.
PVG VALVE SHORT TO GROUND 1250AJP ONLY.
PVG VALVE OPEN CIRCUIT 1250AJP ONLY.
PVG VALVE SHORT TO BATTERY 1250AJP ONLY.
FOX SPARE OUTPUT SHORT TO
GROUND Fox machines ONLY.
FOX SPARE OUTPUT SHORT TO BAT-
TERY Fox machines ONLY.
FOX SPARE OUTPUT OPEN CIRCUIT Fox machines ONLY.
HOUR METER OPEN CIRCUIT This fault cannot be detected during normal operation. It may be reported
during self test.
RESTRICTED TO TRANSPORT –
AXLE LOCKOUT VALVE STB OR OC Machines with electrically released oscillating axles configured ONLY. A short
to battery or open circuit has been detected on axle lockout valve and machine
is restricted to transport position.
RESTRICTED TO TRANSPORT –
PARKING BRAKE STB Machines with electrically released oscillating axles configured ONLY. A short
to battery has been detected on parking brake valve and machine is restricted
to transport position.
Table 6-8. Help Fault Codes, Displayed Faults, and Descriptions - S/N 0300066949 & S/N 1300000001 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
